Hot-Stamping-Machine advmarktech

The machine is controlled by PLC (Programmable Logic Control). Functions of individual head temperature and print time setting, products pitch and pre-set quality are controlled by touch screen 3.5’’ colour LCD monitor. Memory back up of machine settings is included as well as storage of ten sets of parameters for others jobs that may be produced on the machine.

Single or continuous cycle operation, individual head print pressure adjustment, exhaust air silencer, mechanical foil feed, waste foil rewind, indexing table driving by high speed servo motor up to 2000 cycle per hours, die plate leveling system.

The machine operated required 2 to 6 bar of air pressure and has a maximum impression area of 150mm x 100mm with built in leveling. Marking stroke is 20mm to 35mm.
